High-Performance Pan Tilt Unit with 20kg Payload, 360° Continuous Rotation, and IP67-Rated Protection

Name: HighPerformance Pan Tilt Unit with 20kg Payload 360 Continuous Rotation and IP67Rated Protection
Brand: Hope-Wish
Price: 1000 USD

Wholesale High-Performance Pan Tilt Unit with 20kg Payload, 360° Continuous Rotation, and IP67-Rated Protection from china suppliers

Model Number : HP–S080W-PT

Price : 1000

Certification : CE,FCC, ISO

MOQ : 1

Delivery Time : 5~10 days

Payment Terms : T/T,L/C,Western Union

Supply Ability : 2000 units per month

Brand Name : Hope-Wish

Place of Origin : China

Packaging Details : Wooden packaging

Contact Now

Product Description:

Pan Tilt Units – 20kg payload

HP–S020W-PT supports any type of single or multi-part payload through a flexible bracketing system of top and/or side mounting. The real-time command interface supports advanced applications such as video tracking. HP–S020W-PT has been proven in a wide range of mission-critical applications for positioning of cameras, lasers, antennas, or other instruments in both fixed and mobile environments. It is designed for high duty cycles and reliable operation 24/7 in harsh all-weather environments.

High-Performance Pan Tilt Unit with 20kg Payload, 360° Continuous Rotation, and IP67-Rated Protection

Technical Parameters:

Model	HP–S020W-PT
Rotation Angle	Pan: 0° to 360° ; Tilt: -60° to +20°
Rotation Speed	Pan: 0.01 to 20°/s ; Tilt: 0.01 to 10°/s
Preset Positions	200
Positioning Accuracy	±0.1°
Power-On Self-Test	Support
Angle Feedback	Query-based / Real-time
Auto Cruise	2 patterns, 40 points each
Auto Home	Configurable (1～60 min)
Auto Scan	1 pattern
Salt Spray Resistance	No significant surface change after 48hrs continuous spray (PH 6.5-7.2).
Communication Protocol	PELCO_D
Baud Rate	9600bps(2400/4800/115200bps)
Communication Interface	RS422
Power Supply Voltage	DC24V
Power Consumption	≤90W (Operating)
Temperature	-40℃～+65℃(working),-25℃～+65℃(storage)
Payload	20 kg
Dimensions (LWH)	272 x 170 x 300 mm
Weight	32kg
Mounting Type	Top Mount
Self-Locking	Support
Ingress Protection (IP)	IP66
Installation Environment	Fixed Installation
System Type	Open-Loop System (No Encoder)
Top Cable Pass-through	1x Gigabit Ethernet Passthrough Signal Cable (8-core) 1x DC24V Output Power Cable (20A)
Bottom Cable Pass-through	1x Gigabit Ethernet Passthrough Signal Cable (8-core) 1x DC24V Input Power Cable (System Power) 1x RS422 (Unit Communication)

High-Performance Pan Tilt Unit with 20kg Payload, 360° Continuous Rotation, and IP67-Rated Protection

Company:

Hope Wish Photoelectronics Technology Co., Ltd. was established in Jinan high tech Zone and has a core R&D team for laser imaging, infrared thermal imaging detection and tracking technology research and product. Hope-Wish focuses on the research and development of night vision and multispectral imaging technology, by using a variety of image analysis and processing technology based on artificial intelligence to provide users with comprehensive optoelectronic system solutions in long-distance, high-definition, intelligent, multi-purpose, all-weather and complex environments. High-Performance Pan Tilt Unit with 20kg Payload, 360° Continuous Rotation, and IP67-Rated Protection
